layup for internal-corner conduit clips

making conduit clips for internal corners

making conduit clips for internal corners: 2016-10-01 Panasonic DMC-FT1

A BID layup draped over a length of conduit in an internal corner, and held in place with metal weights. The layup has polyethylene sheet top and bottom to prevent it sticking to the form or the weights, and a layer of peel-ply to extract excess epoxy from the layup. It is on a shelf in the boiler cupboard to cure. The layup will be sliced into short lengths to make clips to hold conduit in place on internal corners of the aircraft structure.
